Introduction
Revolutionary smart glass type that does not require electricity at transparent state.
PriWatt Smart Glass technology allows you to switch back and forth between clear glass and opaque, all through a simple electrical current. PriWatt Glass panels contain a film of dispersed liquid crystal molecules in a polymer matrix pressed between two glass sheets. In normal state, without electrical current your glass is transparent. When the current is connected, the molecules immediately disarrange for instantaneous and total privacy.
PriWatt PNLC Glass is composed of a thin film interlayer of liquid crystals dispersed in a polymer matrix laminated between two plastic substrates coated on the inner face with a thin layer of conductive material. By applying a small electrical current, its state can change from transparent to opaque and vice versa. Modified Ethylene Vinyl Acetate (EVA) or Thermoplastic polyurethane (TPU) is used to bond the thin film with the glass.
PriWatt® Reverse Switchable Glass Benefits
PNLC Smart Glass is also known as Reverse PDLC ( Polymer Network Liquid Crystals ) glass which makes it ideal for both residential and commercial settings, providing privacy and dynamic control over the transparency of glass surfaces.
Enhanced Clarity
PriWatt® PNLC offers superior clarity and image quality compared to other smart film technologies. PriWatt® reverse switchable glass provides a high contrast ratio and exceptional visual performance in both transparent and opaque states.
Energy Efficient
The transparent state is available without turning the system on. This is very suitable for the environment where the transparent state is usually required.
Simple Installation
Smart Glass can be easily installed as any regular laminated tempered glass. It can be installed by any certified glazier and connected to the power by any certified electrician.
PriWatt® Glass Applications
Electrically switchable PriWatt® Glass for interior and exterior use
- Dynamic Privacy Control
- Optimized Space
- Flexible Design
- Simple Installation
- Easy Cleaning
Optimized Space:
Replaces thick studded walls with thin partitions or section open floor plans with minimalist solutions. Creates hight-tech conference rooms, private offices, wall dividers, windows and doors, etc.
Electrical Parameters
- Working Voltage (ON): 24-80VAC
- Power Consumption <0.5W/SF
- Responding Time (OFF-ON): <200ms
- Responding Time (ON-OFF): <220ms
Optical Parameters
- Visible Light Transmission (OFF): 88%
- Visible Light Transmission (ON): 65%
- Haze (OFF): 3%
- Haze (ON): 95%
- UV Block: 99%
- View Angle (ON): 160°
Technical Specifications
- Max Size 57 inch x 150 inch
- Operating Temperature: -22℃ ~ 60℃
- Storage Temperature: 22-28℃
- Lifespan (ON): > 15 Years
Multitude of Control Options
PriWatt™ Glass products can be controlled with a variety of devices and can be easily configured to work with your smart home through the z-wave technology.
SIMPLE SWITCH
Control your PriWatt® Glass Products with a simple light switch
DIMMER
A dimmer allows you to control the opacity of the PriWatt® Glass Products
SMARTPHONE
The PriWatt® Glass Products integrates with smartphones for convenient operation
REMOTE
The PriWatt® Glass Products integrates with a variety of remote controls
Z-WAVE
With Z-wave compatibility make the PriWatt® Glass Products a part of your smart home
AUTOMATION SYSTEMS
Testing, testing and some more testing.
To this day make-ups of PriWatt™ PDLC Technology have:
- Passed: ASTM E662 - STANDARD TEST METHOD FOR MEASUREMENT OF SMOKE OBSCURATION USING A CONICAL RADIANT SOURCE IN A SINGLE CLOSED CHAMBER, ON PRIWATT™ Interlayer
- Passed: ASTM E1354, STANDARD TEST METHOD FOR HEAT AND VISIBLE SMOKE RELEASE RATES FOR MATERIALS AND PRODUCTS USING AN OXYGEN CONSUMPTION CALORIMETER IN ACCIDENCE WITH NFPA 130 SECTION A.8.4.1.10, ON PRIWATT™ Interlaye
- Passed: BOMBARDIER SMP 800-C – TOXIC GAS GENERATION FROM MATERIAL COMBUSTION ON PRIWATT™ Interlayer
- Passed: ANSI/CAN 16 CFR 1201 Boiling Test
- Passed: ANSI/CAN IMPACT Test
Certified by UNDERWRITERS LABORATORIES : UL E514182
Modified EVA interlayer successfully passed all tests for Accelerated Weathering, Flexural Properties, Ignition Temperature, Smoke Density, and Rate of Burn in accordance with Miami Dade
US Patent # US11686966B2
PriWatt® Glass Features
Instant Privacy
PriWatt® Glass is undeniably the future of privacy glass and window treatments. Whether it be for commercial, residential or specialty applications, the single biggest benefit PriWatt® Glass offers is complete privacy at your fingertips.
Decrease Energy Consumption
Decrease Energy Consumption
PriWatt® Glass is proven to minimize the effects of high/low external temperatures from affecting your interior temperature, essentially saving you on energy costs.
Block Damaging Radiation
Direct exposure to UV and Infrared radiation is not only bad for your floors and furniture but also to your health. PriWatt® Glass blocks 100% of harmful UV rays and 99% infrared radiation... Protecting you, your loved ones and your valuables.
Easy Maintenance
Maintaining PriWatt® Glass is as easy as it gets. If you wish to clean your smart glass, simply turn it off and use a soft cloth and isopropyl alcohol. It’s really as simple as that.
